DJKXZ-I
Dingjian Medical Devices (Suzhou) Co., Ltd. introduces the DJKXZ-I Hollow Drill—a specialized orthopedic tool engineered for precision in minimally invasive procedures. As a leading Hand-Held Hollow Drill manufacturer, we’ve designed this instrument to meet the unique demands of Kirschner’s needle, intramedullary needle, and other targeted orthopedic surgeries. The DJKXZ-I Hollow Drill combines dual rotational speed modes, optimized hollow design, and strict sterile standards, making it a top choice for surgeons seeking accuracy, efficiency, and patient safety. Whether in hospital operating rooms or specialized clinics, this medical hollow drill delivers consistent performance for complex bone procedures.
The DJKXZ-I Hollow Drill offers flexible speed options: 0-1600rpm for the main unit (ideal for controlled, precise drilling) and 0-1200rpm for the Hand-Held Hollow Drill variant (perfect for rapid, efficient bone penetration). Both modes feature stepless speed regulation and bidirectional rotation, allowing surgeons to tailor operation intensity to surgical needs—from delicate minimally invasive procedures to more demanding bone fixation tasks.
With a clamping range of Φ0.8-8mm (main unit) and Φ0.6-3.2mm (hand-held variant), the drill securely holds drill bits and specialized needles. Its optimized maximum hollow diameter of Φ4.5mm is specifically designed for compatibility with Kirschner’s needles, intramedullary needles, and other orthopedic implants—ensuring seamless insertion and positioning during surgery.
Crafted for medical-grade hygiene, the entire high-temperature sterile hollow drill can withstand rigorous sterilization processes, eliminating cross-contamination risks. The one-piece closed back cover enhances structural integrity, while corrosion-resistant materials ensure longevity even with frequent use and disinfection.
Powered by a green and environmentally friendly battery, the drill requires no additional disinfection of power components—reducing operational costs and environmental impact. The long-lasting battery provides consistent power throughout surgeries, eliminating the need for mid-procedure recharging.
Parameter | DJKXZ-I Hollow Drill (Main Unit) | Hand-Held Hollow Drill Variant |
Model | DJKXZ-I | DJKXZ-I (Hand-Held) |
Rotational Speed | 0-1600 revolutions per minute | 0-1600 revolutions per minute |
Clamping Range | Φ0.8-8mm | Φ0.6-3.2mm |
Maximum Hollow Diameter | Φ4.5mm | Φ4.5mm |
Rotation Direction | Forward & Reverse | Forward & Reverse |
Sterilization Compatibility | High-temperature sterilizable | High-temperature sterilizable |
Power Source | Eco-friendly rechargeable battery | Eco-friendly rechargeable battery |
Key Application | Kirschner’s needle/intramedullary needle surgeries | Minimally invasive orthopedic procedures |
Procedure-Specific Design: Φ4.5mm hollow diameter perfectly fits Kirschner’s needles and intramedullary needles, reducing surgical complexity.
Dual Speed Flexibility: 1600rpm precision mode and 1600rpm high-speed mode adapt to diverse surgical scenarios.
Sterile & Safe: High-temperature sterilization compatibility meets global medical safety standards, protecting patients and staff.
Precision Clamping: Secure grip on small-diameter needles and drill bits prevents slippage, enhancing surgical accuracy.
Eco-Friendly Operation: Green battery technology aligns with sustainability goals while ensuring reliable performance.
The Kirschner needle hollow drill excels in stabilizing small bone fractures (e.g., finger, toe, or wrist fractures) using Kirschner’s needles—providing precise drilling and needle placement with minimal tissue trauma.
Ideal for long bone fracture repair (e.g., femur, tibia, or humerus), the drill facilitates intramedullary needle insertion through its optimized hollow design—reducing surgery time and improving fixation stability.
Perfect for arthroscopic procedures, joint reconstruction, and bone biopsy—its compact design and precise control minimize incision size, accelerate patient recovery, and reduce post-operative complications.
A valuable tool for treating sports-related bone injuries (e.g., stress fractures, ligament anchor fixation)—delivering the speed and precision needed for athlete-specific care.
To meet diverse clinical needs, we offer comprehensive customization service for the DJKXZ-I Hollow Drill:
Hollow diameter adjustment (Φ3.0mm to Φ6.0mm)
Rotational speed range modification (0-600rpm to 0-1600rpm)
Ergonomic handle design (custom grip size for surgeon comfort)
Battery type customization (lithium-ion or rechargeable nickel-metal hydride)
Branding and labeling (hospital logo, serial number engraving)
